ZSi-Foster 3L56 QD3-L30
  1. pin-int

ZSi-Foster 3L56 QD3-L30

ZSi-Foster 3L56 Plug, 1/2 in Quick-Disconnect x 3/4 in MNPT, Steel

  • Manufacturer: Ideal Clamp Products, Inc
  • Brand Name: ZSi-Foster
  • Part#: QD3-L30
  • MPN: 3L56
  • Qty. Interval: 1
  • loading NASHVILLE, TN
  • loading Available at All Branches
  • UOM: EA

ZSi-Foster Plug, Series: 3FRL Series, Plug Fitting, 1/2 in Connection Size 1, Quick-Disconnect Connection Type 1, 3/4 in Connection Size 2, MNPT Connection Type 2, Quick-Disconnect|MNPT Connection Type, Steel, Steel Material Construction, 1-1/16 in Hex, 3/4-14 Thread, 2.02 in L, 300 psig Maximum Operating Pressure, Additional Information: 1-Way Shut-Off, Buna-N Seal

Additional Information      :      1-Way Shut-Off, Buna-N Seal
Connection Size 1      :      1/2 in
Connection Size 2      :      3/4 in
Connection Type 1      :      Quick-Disconnect
Connection Type 2      :      MNPT
Connection Type      :      Quick-Disconnect|MNPT
Dimensions      :      2.02 in L
Fitting Type      :      Plug
Hex Size      :      1-1/16 in
Material Construction      :      Steel
Material      :      Steel
Maximum Operating Pressure      :      300 psig
Series      :      3FRL Series
Thread Size      :      3/4-14
  • Automatic push-to-connect, twist-to-release operation
  • High flow capacity, ring lock
  • Will not disconnect when hose is dragged on the ground
