OROFLEX® OF20B-800X660 HSWDPV-OF20B-800X660

OROFLEX® OF20B-800X660 Discharge Hose, 8 in Nominal, 660 ft L, 200 psi, NBR/PVC Tube, Black

  • Manufacturer: KURIYAMA OF AMERICA, INC
  • Brand Name: OROFLEX®
  • Part#: HSWDPV-OF20B-800X660
  • MPN: OF20B-800X660
  • UPC: 822353199299
  • Qty. Interval: 1
  • loading NASHVILLE, TN
  • loading Available at All Branches
  • UOM: FT

OROFLEX® Discharge Hose, Series: OF20B Series, Heavy-Duty Hose, 8 in Nominal, 8.091 in Inside Dia, 660 ft Length, NBR/PVC Tube, NBR/PVC Cover, Polyester Reinforcement, Black Hose Color, 200 psi, Abrasion, Chemical, Oil, UV, Weather Resistance Properties, 176 deg F Temperature High, -20 deg F Temperature Low, 0.15 in Wall Thickness, 77150 lb Tensile, Additional Information: 500 psi Burst Pressure

Additional Information      :      500 psi Burst Pressure
Cover Material      :      NBR/PVC
Hose Color      :      Black
Hose Type      :      Heavy-Duty
Inside Diameter      :      8.091 in
Length      :      660 ft
Nominal Size      :      8 in
Pressure Rating      :      200 psi
Reinforcement      :      Polyester
Resistance Properties      :      Abrasion, Chemical, Oil, UV, Weather
Series      :      OF20B Series
Temperature High      :      176 deg F
Temperature Low      :      -20 deg F
Tensile Strength      :      77150 lb
Tube Material      :      NBR/PVC
Wall Thickness      :      0.15 in
  • Black PVC/nitrile hose using an extruded through the weave process with circular woven high tenacity polyester reinforcement
  • Specially developed PVC/nitrile material provides superior abrasion, UV, chemical and oil resistance compared to PVC hoses
  • Specially designed weave pattern provides resistance to snaking, kinking, stretching and twisting
  • Manufactured in special 660 ft lengths to reduce possible leaking points
  • Flat hose design rolls up into tight coils for easy storage and transport, takes up less space than other hoses
  • Made in Europe
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/OROFLEX_OF20B_600X660_Specification_Sheet.pdf
