Gates® 70853 HY10MEGATECH-TK
  1. pin-int

Gates® 70853 HY10MEGATECH-TK

Gates® 70853 High-Temperature Oil-Air Return Hose, 1000 psi, Chlorinated Polyethylene Tube

  • Manufacturer: Gates Corp
  • Brand Name: Gates®
  • Part#: HY10MEGATECH-TK
  • MPN: 70853
  • Qty. Interval: 1
  • loading NASHVILLE, TN
  • loading Available at All Branches
  • UOM: FT

Recommended for air brake, pressurized hot oil return lines and rotary oil/air compressor lines. Meets the requirements of DOT FMVSS 106-74, SAE J1402 for Air Brake Hose (-4, 6, 8, 10), and SAE J1405 performance specifications for high-temperature transmission and lubricating oil systems using petroleum base oils. Not recommended for gasoline or diesel fuel applications.

Gates® High-Temperature Oil-Air Return Hose, Oil-Air Return Hose, 10 Dash, 5/8 in Inside Diameter, 0.93 in Outside Diameter, Chlorinated Polyethylene Tube, Synthetic Rubber Cover, One Braid of High tensile Steel Wire Reinforcement, 4 in Bend Radius, 1000 psi, Resistance Properties: Ozone, Weather, Temperature High: 300 deg F, Temperature Low: -40 deg F, For Use With: MegaCrimp® Couplings (G25) Section G, Additional Information: 4000 psi Burst Pressure, 30 inHg Vacuum

Additional Information      :      4000 psi Burst Pressure, 30 inHg Vacuum
Bend Radius      :      4 in
Cover Material      :      Synthetic Rubber
Dash Size      :      10
For Use With      :      MegaCrimp® Couplings (G25) Section G
Hose Type      :      Oil-Air Return
Inside Diameter      :      5/8 in
Outside Diameter      :      0.93 in
Pressure Rating      :      1000 psi
Reinforcement      :      One Braid of High tensile Steel Wire
Resistance Properties      :      Ozone, Weather
Temperature High      :      300 deg F
Temperature Low      :      -40 deg F
Tube Material      :      Chlorinated Polyethylene
  • Very good resistance to weathering and ozone
  • Meets the requirements of SAE J1405 performance specifications for use in high-temperature transmission oil systems and high-temperature lubrication oil systems using petroleum-based oils
  • MegaTech® is True-Bore ID Gates® technical spec 300 deg F tube stock with textile braid cover
  • MegaTech® is compatible with a variety of fluids such as hydraulic oil, phosphate esters, di-esters
  • MegaTech® 1000 has a black textile braid cover
  • -4 to -20 validated with MegaCrimp®
  • Working pressure: 2.1 Mpa
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Gates_70851_Catalog.pdf
