DK-LOK® DMC2-2N-S HYFC2-2MP-INST-SS

DK-LOK® DMC-N Series DMC2-2N-S Connector, 1/8 in Tube x 1/8 in MNPT, Stainless Steel

  • Manufacturer: DK-LOK USA
  • Brand Name: DK-LOK®
  • Part#: HYFC2-2MP-INST-SS
  • MPN: DMC2-2N-S
  • Qty. Interval: 1
  • loading NASHVILLE, TN
  • loading Available at All Branches
  • UOM: EA

DK-LOK® Connector, DMC-N Series, Connector Fitting, 1/8 in Connection Size 1, Connection Type 1: Tube, 1/8 in Connection Size 2, Connection Type 2: MNPT, Tube|MNPT Connection, Stainless Steel, Material Construction: 316/316L Stainless Steel, 7/16 in Hex, 30.5 mm L

Connection Size 1      :      1/8 in
Connection Size 2      :      1/8 in
Connection Type 1      :      Tube
Connection Type 2      :      MNPT
Connection Type      :      Tube|MNPT
Dimensions      :      30.5 mm L
Fitting Type      :      Connector
Hex Size      :      7/16 in
Material Construction      :      316/316L Stainless Steel
Material      :      Stainless Steel
Series      :      DMC-N Series
