apg™ S2X13 ORM2 X 13S

apg™ S2X13 O-ring, 13 mm ID, 2 mm Thick, Silicone, 70 Durometer

  • Manufacturer: APG
  • Brand Name: apg™
  • Part#: ORM2 X 13S
  • MPN: S2X13
  • Qty. Interval: 1
  • loading NASHVILLE, TN
  • loading Available at All Branches
  • UOM: EA

Recommended for applications requiring a wide temperature range and good dry heat resistance. Good weather and ozone resistance. Limited oil resistance. Not normally recommended for dynamic sealing applications due to relatively poor tensile and tear strength and relatively low abrasion resistance.

apg™ O-ring, Metric System of Measurement, 13 mm Inside Dia, 2 mm Thickness, 70 Durometer, Round Cross Section, Silicone, Black, -80 to 450 deg F, Additional Information: +/-0.19 mm ID Tolerance, +/-0.08 mm Cross Section Tolerance

Additional Information      :      +/-0.19 mm ID Tolerance, +/-0.08 mm Cross Section Tolerance
Color      :      Black
Cross Section Shape      :      Round
Durometer      :      70
Inside Diameter      :      13 mm
Material      :      Silicone
System of Measurement      :      Metric
Temperature Rating      :      -80 to 450 deg F
Thickness      :      2 mm
