Alfagomma® AlfaCrimp D-1616-C62S 1-Piece Non-Skive Crimp Fitting, 1 in Hose x 1 in SAE Code 62 Flange
Available at NASHVILLE, TN
Available at All Branches
Alfagomma® AlfaCrimp 1-Piece Non-Skive Crimp Fitting, Series: D Series, Straight Hose End Fitting, Connection Size 1: 1 in, Connection Type 1: Hose, Connection Size 2: 1 in, Connection Type 2: SAE Code 62 Flange, Hose|Flanged Connection, 16 Hose Dash Size, 56.4 mm Cut-Off Factor, For Use With: Alfabiotech 3000 1-1/4 to 2 in ID, 4000 3/8 to 1-1/4 in ID 4-Wire Spiral Hoses and Above 1 in ID Wire Braided Hoses, Dimension Standards: SAE J518, 6000 psi Maximum Operating Pressure
| Connection Size 1 | : | 1 in |
| Connection Size 2 | : | 1 in |
| Connection Type 1 | : | Hose |
| Connection Type 2 | : | SAE Code 62 Flange |
| Connection Type | : | Hose|Flanged |
| Cut-Off Factor | : | 56.4 mm |
| Dimension Standards | : | SAE J518 |
| Fitting Type | : | Straight Hose End Fitting |
| For Use With | : | Alfabiotech 3000 1-1/4 to 2 in ID, 4000 3/8 to 1-1/4 in ID 4-Wire Spiral Hoses and Above 1 in ID Wire Braided Hoses |
| Hose Dash Size | : | 16 |
| Maximum Operating Pressure | : | 6000 psi |
| Series | : | D Series |
